35-66kV Oil Immersed Transformers

This product implements the national standard GB1094 "Power Transformer" and GB/T6451 "Three-phase oil-immersed power transformer technical parameters and requirements."

Send Inquiry

Product introduction

This product implements the national standard GB1094 "Power Transformer" and GB/T6451 "Three-phase oil-immersed power transformer technical parameters and requirements."
The S11 series is a three-phase oil-immersed distribution transformer. The core material is selected from DQ133-30 (type 9),30QG120 (type 11), 23RK090 (type 13), 23RK080 (type 14)and other cold -rolled silicon steel sheets. The core material used in actual production is not lower than the pattern requirements.
The product adopts a fully sealed corrugated oil tank structure. The transformer oil and the surrounding air do not contact, so the transformer oil will not absorb the external moisture, and thus will not reduce the insulation strength, in addition, oxygen can not enter the fuel tank, thus avoiding the aging of the insulation material, improving the service life of the product also improves social benefits.

Product features

Energy Savings: The S11 type has an average 30% reduction in no-load losses compared to the GB/T6451. an average 25% reduction in load loss, and an average 20% reduction in operating costs.
Long service life: The transformer oil tank adopts a fully sealed structure, and the fuel tank and the box edge can be bolted or welded to death, and the transformer oil does not come in contact with air to extend the service life.
High operating reliability: Improvements are made to the components of the fuel tank seal, increasing reliability and improving the process level to ensure the reliability of the seal.
Small footprint The S11-M series transformer tank uses a corrugated plate radiator. When the oil temperature changes, the thermal expansion and contraction of the corrugated plate can replace the role of the oil conservator. The corrugated plate tank has a beautiful appearance and a small footprint.

Technical Parameter

6kV, 10kV 30kVA- 2500kVA three-phase oil immersed electrical steel core non excitation voltage regulating distribution transformer

Energy efficiency grade					1		2		3		Impedance %
Loss level code					14		13		11
Rated capacity (kVA)	Voltage combination & tapping range			Connection-group code	No-load loss W	Load loss W	No-load loss W	Load loss W	No-load loss W	Load loss W
Rated capacity (kVA)	H.V. (kV)	High voltage tapping range %	L.V. (kV)	Connection-group code	No-load loss W	Load loss W	No-load loss W	Load loss W	No-load loss W	Load loss W
30	6 6.3 10 10.5 11	±2x2.5 ± 5	0.4	Dyn11 Yzn11 Yyn0	80	505/480	80	630/600	100	630/600	4.0
50					100	730/695	100	910/870	130	910/870
63					110	870/830	110	1090/1040	150	1090/1040
80					130	1050/1000	130	1310/1250	180	1310/1250
100					150	1260/1200	150	1580/1500	200	1580/1500
125					170	1510/1440	170	1890/1800	240	1890/1800
160					200	1850/1760	200	2310/2200	280	2310/2200
200					240	2180/2080	240	2730/2600	340	2730/2600
250					290	2560/2440	290	3200/3050	400	3200/3050
315					340	3060/2920	340	3830/3650	480	3830/3650
400					410	3610/3440	410	4520/4300	570	4520/4300
500					480	4330/4120	480	5410/5150	680	5410/5150
630				Dyn11 Yyn0	570	4960	570	6200	810	6200	4.5
800					700	6000	700	7500	980	7500
1000					830	8240	830	10300	1150	10300
1250					970	9600	970	12000	1360	12000
1600					1170	11600	1170	14500	1640	14500
2000					1550	14600	1550	18300	1940	18300	5.0
2500					1830	16900	1830	21200	2290	21200	5.0

6kV, 10kV 630kVA- 6300kVA three-phase oil immersed electrical steel core non excitation voltage regulating distribution transformer

Energy efficiency grade					1		2		3		Impedance %
Loss level code					14		13		11
Rated capacity (kVA)	Voltage combination & tapping range			Connection-group code	No-load loss W	Load loss W	No-load loss W	Load loss W	No-load loss W	Load loss W
Rated capacity (kVA)	H.V. (kV)	High voltage tapping range %	L.V. (kV)	Connection-group code	No-load loss W	Load loss W	No-load loss W	Load loss W	No-load loss W	Load loss W
630	6 6.3 10 10.5	±2x2.5 ± 5	3 3.15 6.3	Yd11 Dy11	656	6230	656	6920	820	6920	5.5
800					800	7610	800	8460	1000	8460
1000					944	8920	944	9910	1180	9910
1250					1120	10500	1120	11700	1400	11700
1600					1340	12700	1340	14100	1680	14100
2000					1610	15200	1610	16900	2010	16900
2500					1900	17600	1900	19600	2370	19600
3150					2240	20700	2240	23000	2800	23000
4000	10 10.5		3.15 6.3		2760	24600	2760	27300	3450	27300
5000					3280	28200	3280	31300	4100	31300
6300					3910	31500	3910	35000	4890	35000

6kV, 10kV 200kVA- 2500kVA three-phase oil immersed electrical steel core non excitation voltage regulating distribution transformer

Energy efficiency grade					1		2		3		Impedance %
Loss level code					14		13		11
Rated capacity (kVA)	Voltage combination & tapping range			Connection-group code	No-load loss W	Load loss W	No-load loss W	Load loss W	No-load loss W	Load loss W
Rated capacity (kVA)	H.V. (kV)	High voltage tapping range %	L.V. (kV)	Connection-group code	No-load loss W	Load loss W	No-load loss W	Load loss W	No-load loss W	Load loss W
200	6 6.3 10 10.5	±4x2.5	0.4	Dyn11 Yyn0	304	2610	304	2900	380	2900	4.0
250					352	3080	352	3420	440	3420
315					424	3690	424	4100	530	4100
400					512	4460	512	4950	640	4950
500					608	5300	608	5890	760	5890
630					768	6530	768	7260	960	7260	4.5
800					896	8000	896	8890	1120	8890
1000					1090	9360	1090	10400	1360	10400
1250					1250	11100	1250	12300	1560	12300
1600					1540	13200	1540	14700	1920	14700
2000					1820	16700	1820	18600	2270	18600	5.0
2500					2140	19400	2140	21600	2680	21600	5.0

6kV, 10kV 5kVA- 160kVA single-phase oil immersed electrical steel strip core non excitation voltage regulating distribution transformer

Energy efficiency grade					1		2		3		Impedance %
Loss level code					14		13		11
Rated capacity (kVA)	Voltage combination & tapping range			Connection-group code	No-load loss W	Load loss W	No-load loss W	Load loss W	No-load loss W	Load loss W
Rated capacity (kVA)	H.V. (kV)	High voltage tapping range %	L.V. (kV)	Connection-group code	No-load loss W	Load loss W	No-load loss W	Load loss W	No-load loss W	Load loss W
5	6 6.3 10 10.5 11	±5 ±2x2.5	2x(0.22~0.24) OR 0.22~0.24	Li0 Li6	24	117	24	130	30	130	3.0
10					36	212	36	235	45	235
16					44	297	44	330	55	330
20					52	346	52	385	65	385
30					64	504	64	560	80	560
40					80	630	80	700	100	700	3.5
50					96	769	96	855	120	855
63					116	918	116	1020	145	1020
80					128	1230	128	1260	160	1260
100					152	1340	152	1480	190	1480
125					184	1580	184	1760	230	1760
160					232	1920	232	2130	290	2130

20kV 30kVA ~ 2500kVA three phase oil immersed electrical steel core non excitation voltage regulating distribution transformer

Energy efficiency grade					1		2		3		Impedance %
Loss level code					14		13		11
Rated capacity (kVA)	Voltage combination & tapping range			Connection-group code	No-load loss W	Load loss W	No-load loss W	Load loss W	No-load loss W	Load loss W
Rated capacity (kVA)	H.V. (kV)	High voltage tapping range %	L.V. (kV)	Connection-group code	No-load loss W	Load loss W	No-load loss W	Load loss W	No-load loss W	Load loss W
30	20	± 5	0.4	Dyn11 Yzn11 Yyn0	80	621/594	80	690/660	100	690/660	5.5
50					104	909/864	104	1010/960	130	1010/960
63					120	1080/1040	120	1200/1150	150	1200/1150
80					144	1290/1230	144	1440/1370	180	1440/1370
100					160	1560/1490	160	1730/1650	200	1730/1650
125					192	1870/1780	192	2080/1980	240	2080/1980
160					232	2290/2180	232	2540/2420	290	2540/2420
200					272	2700/2570	272	3000/2860	340	3000/2860
250					320	3170/3020	320	3520/3350	400	3520/3350
315					384	3790/3610	384	4210/4010	480	4210/4010
400					456	4470/4260	456	4970/4730	570	4970/4730
500					544	5350/5090	544	5940/5660	680	5940/5660
630					648	6140	648	6820	810	6820	6.0
800					784	7430	784	8250	980	8250
1000					920	10200	920	11300	1150	11300
1250					1100	11900	1100	13200	1380	13200
1600					1330	14400	1330	16000	1660	16000
2000					1560	17200	1560	19100	1950	19100
2500					1870	20000	1870	22200	2340	22200

20kV 5KVA ~ 160K\A single phase oil immersed electrical steel strip core non excitation voltage regulating distribution transformer

Energy efficiency grade					1		2		3		Impedance %
Loss level code					14		13		11
Rated capacity (kVA)	Voltage combination & tapping range			Connection-group code	No-load loss W	Load loss W	No-load loss W	Load loss W	No-load loss W	Load loss W
Rated capacity (kVA)	H.V. (kV)	High voltage tapping range %	L.V. (kV)	Connection-group code	No-load loss W	Load loss W	No-load loss W	Load loss W	No-load loss W	Load loss W
5	20	±5	2x(0.22~0.24) OR 0.22~0.24	Li0	24	122	24	135	30	135	3.5
10					36	221	36	245	45	245
16					44	311	44	345	55	345
20					52	364	52	405	65	405
30					64	526	64	585	80	585
40					80	662	80	735	100	735
50					96	810	96	900	120	900
63					116	963	116	1070	145	1070
80					128	1190	128	1330	160	1330
100					152	1400	152	1560	190	1560
125					184	1660	184	1840	230	1840
160					232	2010	232	2240	290	2240

35kV 50kVA ~ 2500kVA three phase oil immersed electrical steel strip core non excitation voltage regulating distribution transformer

Energy efficiency grade					1		2		3		Impedance %
Loss level code					14		13		11
Rated capacity (kVA)	Voltage combination & tapping range			Connection-group code	No-load loss W	Load loss W	No-load loss W	Load loss W	No-load loss W	Load loss W
Rated capacity (kVA)	H.V. (kV)	High voltage tapping range %	L.V. (kV)	Connection-group code	No-load loss W	Load loss W	No-load loss W	Load loss W	No-load loss W	Load loss W
50	35 38.5	±2x2.5 ±5	0.4	Dyn11 Yyn0	128	1080/1030	128	1200/1140	160	1200/1140	6.5
100					184	1810/1720	184	2010/1910	230	2010/1910
125					216	2130/2030	216	2370/2260	270	2370/2260
160					224	2540/2410	224	2820/2680	280	2820/2680
200					272	2990/2840	272	3320/3160	340	3320/3160
250					320	3560/3380	320	3950/3760	400	3950/3760
315					384	4280/4080	384	4750/4530	480	4750/4530
400					464	5170/4920	464	5740/5470	580	5740/5470
500					544	6220/5920	544	6910/6580	680	6910/6580
630					664	7070	664	7860	830	7860
800					784	8460	784	9400	980	9400
1000					920	10400	920	11500	1150	11500
1250					1120	12500	1120	13900	1400	13900
1600					1350	14900	1350	16600	1690	16600
2000					1590	17700	1590	19700	1990	19700
2500					1890	20900	1890	23200	2360	23200
